Measure two different things before ordering a sofa: how the assembled layout works in the room, and how the delivery components reach it. A room fit does not prove an access fit. Keep both sets of measurements with the exact product and configuration you plan to order.
Draw the usable room, not just wall lengths
Record the room outline, doors, windows, fixed cabinetry and radiators or other immovable features. Mark which way doors open and where people normally walk. A bay, alcove or angled wall can change the usable area. Use centimetres consistently and label each dimension rather than relying on an unlabeled sketch.
Place the full sofa footprint
Use the selected model’s overall dimensions and configuration diagram. Include a chaise projection, curved back and any separate ottoman you will regularly use. Do not substitute seat count for width. If you plan a modular alternative, check that the supplied sections actually support it before drawing it as a future arrangement.
Add the rest of the furniture
Mark the coffee table, armchair, TV furniture and storage openings. Then walk the room as it will be used, including a route to a balcony or adjoining space. Try a temporary floor outline for the sofa and table. This reveals whether the room remains comfortable to move through when the furniture is in place.
Measure each access stage
Record clear doorway openings rather than only the nominal door size. Measure corridor widths, turns, stair landings, lift doors and the inside cabin. Include the route outside the building and any booking or access restriction. Photographs of tight points are useful alongside dimensions, especially where a piece may need to turn.
Compare with packed components
The delivery comparison needs the largest component’s full length, width, height and weight. The assembled sofa dimensions are not a substitute. Ask whether legs or packaging can be removed under the actual handling process. Do not assume a mathematically smaller width guarantees a practical fit through a bend or stairwell.
Send one clear fit enquiry
Include the product link, selected variant, labelled room plan, route measurements and photographs of uncertain points. Ask for confirmation of missing component data before ordering. A two-dimensional room planner is useful for footprint comparisons, but cannot guarantee handling access or capture every three-dimensional constraint.
Compare actual products
These examples use the dimensions currently listed for the selected models. Check the selected configuration and product details before ordering; the conceptual interior image is not a product photograph.
| Model | Listed overall dimensions | Compare |
|---|---|---|
| Baron 5-Seater Leather Corner Sofa Set | 360.68 L x 281.94 W x 81.28 H cm | View product |
| Conor 6-Seater Fabric Chaise Lounge Set | 518.16 L x 360.68 W x 81.28 H cm | View product |
| Coen 6-Seater Leather Chaise Louge Set | 518.16 L x 360.68 W x 81.28 H cm | View product |
Frequently asked questions
Should I measure in centimetres or millimetres?
Either can work if every value is clearly labelled and converted consistently. The planning tools use centimetres.
Can overall sofa width prove doorway fit?
No. You need delivery-component dimensions and the full route, including height and turns.
What should I send for a fit question?
Send the exact product/variant, a labelled room and access sketch, dimensions and photographs of tight points.
